1. Specifically designed to withstand the high torque levels encountered in screw pump applications.
2. Equipped with improved threading to maximize torque capacity.
3. The enhanced threading increases torque force by at least 50% compared to traditional API threaded connections.
4. Drive rods are available in rod body diameters of 1 inch (25.40 mm), 1-1/4 inches (31.75 mm), and 1-1/2 inches (38.10 mm).
5. Full-length heat treatment is applied to eliminate residual stress, with air quenching and tempering to refine and homogenize the grain structure.
Main Mechanical Properties
|
Grade |
Tensile Strength Rm MPa |
Yield Strength Rel MPa |
Elongation A 200mm % |
Reduction of Area Z % |
Impact Toughness（Type）J |
|
D |
795～965 |
≥590 |
≥10 |
≥50 |
≥60 |
|
H |
965～1195 |
≥795 |
≥10 |
≥45 |
≥60 |
Specifications:
|
standard size （ Inch） |
outer diameter MM |
end dimensions（Inch） |
Leghth(MM) |
|
|
Sucker Rod |
Pony Rod |
|||
|
1 |
25.40 |
7/8 |
7620 8000 9140 |
600, 1200 1800, 2400 3000, 3600 |
|
11/8 |
28.58 |
1 |
||
|
11/4 |
31.80 |
1 |
||
|
11/2 |
38.10 |
11/8 |
||
